dynamic application

PMXX^®️

DEVICE NET

Applicative Features

5 MILLION
Guaranteed Cycles

10,0m/s2
Acceleration

15,0m
Cable length

200,0m/min
Travel speed

Minimum Bending radius

Cross section min (mm²)	Cross section max (mm²)	Dynamic Installation	Static installation
0.20	1.65	10xØ	6xØ

Description

UL/CSA certified flexible cables for industrial devices that work with the DEVICE NET^® data transmission standard, designed for Static application between the central controlling unit and the input/output peripheral components. The construction of these cables is designed to limit electromagnetic interference for optimal and clean communication.

Approvals

AWM STYLE 20233 80°C 300V

AWM I/II A/B 80°C 300V

2014/35/CEE

2014/30/EU

2011/65/UE

1907/2006

IEC 60754-1

Technical data

dynamic

-40°C +80°C

static

-50°C +80°C

Nominal voltage

300V

Test Voltage

2000V

Insulation resistance

Nominal impedance

120±10%

Construction features

Data pair
	Conductor	CL6 Extra-flexible. Tinned copper
	Insulation	Expanded polyethylene (PEE)
	Insulation Color	Blue core and white core.
	screen	Tape shield Polyester inside / Alluminium outside 100 % ± 5 %

Supply pair
	Conductor	CL6 Extra-flexible. Tinned copper
	Insulation	Expanded polyethylene (PEE)
	Insulation Color	black and red
	screen	Tape shield Polyester inside / Alluminium outside 100 % ± 5 %

Overall Stranding
	DRAIN WIRE	Drain wire Tinned copper
	screen	Shield Tinned copper 85 % ± 5 %
	SEPARATION LAYER	Tape Non-woven tape
	Sheath	Polyurethane compound (TMPU)
	Sheath Colour	Violet, RAL: 4001, desina: yes

Products features

Fire performance

FT1 (CSA)

IEC 60332-1-2 (EU)

Oil performance

1581 (UL)

IEC 60811-404 (EU)

CEI EN 50363-10-2 (EU)

IRM 902

Uv performance

UV RESISTANT

TECO code	n° cores x cross-section	Capacitance (nF/Km)	cut	rolls (m)	drums (m)	Ext Ø (mm)	Weight (kg/km)
14391	[(2xAWG24)SN+(2xAWG22)SN]ccST	40		100		7	65
14423	[(2xAWG18)SN+(2xAWG15)SN]ccST	46		100	500	11.6	175

TECO code

n° cores x cross-section

Capacitance (nF/Km)

cut

rolls (m)

drums (m)

Ext Ø (mm)

Weight (kg/km)

14391

[(2xAWG24)SN+(2xAWG22)SN]ccST

100

14423

[(2xAWG18)SN+(2xAWG15)SN]ccST

100

500

11.6

175
