Static application

FE

CANOPEN 300V

Applicative Features

Minimum Bending radius
Cross section min (mm2) Cross section max (mm2) Dynamic Installation Static installation
0.22 0.22 6.0xØ
CAN bus

Description

UL/CSA certified flexible cables for industrial devices that work with the CANOPEN® data transmission standard, designed for Static application between the central controlling unit and the input/output peripheral components. The construction of these cables is designed to limit electromagnetic interference for optimal and clean communication.

Approvals

Certification image not found
AWM I/II A/B 80°C 300V
Certification image not found
2014/35/CEE
Certification image not found
2014/30/EU
Certification image not found
2011/65/UE
Certification image not found
1907/2006
Certification image not found
AWM STYLE 2571 80°C

Technical data

During installation

-5 °C +80 °C

static

-30 °C +80 °C

Nominal voltage

300 V

Test Voltage

1500 V (a.c. 50 Hz)

Nominal impedance

120 ± 15 % ohm

Construction features

Twisted pair
Conductor

CL2 Flexible. Bare Copper
Insulation

Polyethylene compound (PE)
Insulation Color

Colours sequence refers to DIN 47100 standard

Overall Stranding

filler

Filler Polypropylene

SEPARATION LAYER

Tape PET Polyester compound

screen

Shield braid Tinned Copper 85 % ± 5 %
Sheath

PVC compound.
Sheath Colour

Violet, RAL: 4001, desina: no

Products features


Fire performance

UL 1581 sec.1061 Cable flame

FT1 (CSA)

IEC 60332-1-2


Oil performance

UL 1581

IEC 60811-404

EN 50363-4-1

VDE 0207-363-4-1

TECO code n° cores x cross-section cut rolls (m) drums (m) Ext Ø (mm) Weight (kg/km)

27372

(1x2x0,22)ST

(1x2xAWG24)ST

100

500

5.9

44
